Wilbers fork spring kit, linear, for HONDA CB 500 F, Type PC 45, Model Year 13-15, 30 mm lowering

Image shows sample

€161.10 gross €135.38 net €179.00 RRP incl. VAT

Article number: WI-601-0475-00

In ca. 4 working days

Product details

Wilbers fork spring kit, linear, for HONDA CB500F, Type PC45, Model Year 13-15, 30 mm lowering incl. reducing sleeve, (fork oil must be ordered separately), with ABE according to application list

General description

Depending on the application, Wilbers offers progressive or linear fork springs, manufactured from the best and highest quality chrome-silicon steel. For touring and touring sport, we generally recommend a progressive fork spring to optimise responsiveness and, on the other hand, increase bottoming resistance. The combination of the 'Zero Friction' fork springs with the specially developed Wilbers fork oil and observing the correct air chamber for the respective vehicle is very important. If desired, individual tuning can be achieved in special cases by changing the air chamber.
For motorsport applications, we recommend the very light linear chrome-silicon fork springs from Wilbers, which were co-developed by the motorsport team.

'ZERO friction' friction reduction through vibratory finishing:
During vibratory finishing, the componentes to be processed, such as Wilbers fork springs, are placed together with an abrasive media specifically designed for this purpose in a vibrating container, known as a trough vibrator.
The vibrations of the container create a relative movement between the workpiece and the abrasive media, leading to a smoothing of the component upper surface through constant rubbing. At the end of the process, a fine, glossy surface is achieved.
For Wilbers fork springs, this reduction in surface roughness means a minimisation of friction = ZERO friction.

Each fork spring set includes a recommendation regarding the viscosity of the fork oil and the air chamber height in the fork. These values have been determined by experienced Wilbers technicians and ensure optimal riding comfort and feedback at the front wheel.

Note: please order the fork oil separately.
