BITUBO Cartridge for MV Agusta F3 675/800 2012-19 and F3 675/800 Type F1 2015-19
€1,257.69 gross €1,323.88 UVP brutto
Product number:
BI-MV002-EBH50WO
Product details
BITUBO closed cartridge without springs, 13mm longer than original, spring preload 15mm (15 turns) adjustable, one leg with rebound damping adjustable in 24 clicks, one leg with compression damping damping adjustable in 24 clicks; for MV AgustaF3 675/800, Type F3, model year 2012-19
F3 675/800 RC, Type F1, model year 2015-19
General description
The EBH gas-pressurised closed cartridge contains a range of innovative features.Light components:
This product is manufactured with a high proportion of special light alloys, which significantly reduces weight.
The adjusters for the various setting options are located on the upper end caps:
The spring preload can be adjusted via 15 turns, while rebound and compression damping have been distributed between the two cartridges, making adjustment simpler and easier.
The goal:
To offer the rider the greatest stability on the front wheel, achieved through perfect feedback from the front wheel, even under the heaviest strain on the brakes and in extreme lean angles. Due to direct hydraulic control, grip is increased when entering and exiting a corner, and more even tire wear is achieved.
Features:
- Hydraulic piston with FPS® system - made of aluminium
- with anti-friction coating
- polyurethane end stop
- co-axial compensation chamber
- hydraulic oil & grease separated
- compression damping 24 clicks
- Rebound 24 clicks
- spring preload 15 mm - 15 turns
- 13mm longer than original
| fork filter: | Cartridge |
|---|
| Manufacturer | Model | Additional designation | Type | Model year | Position | ccm |
|---|---|---|---|---|---|---|
| MV Agusta | F3 675 | RC | F1 EURO4 | 2017 - 2019 | fronte | 675 |
| MV Agusta | F3 675 | F3 | 2012 - 2019 | fronte | 675 | |
| MV Agusta | F3 800 | RC | F1 EURO4 | 2015 - 2019 | fronte | 800 |
| MV Agusta | F3 800 | F3 | 2012 - 2019 | fronte | 800 |
