Wilbers shock absorber 633 Adjustline for Harley Davidson 883 Iron 2010-

Product Details

Wilbers Performance Suspension Adjustline 633 Competition P, stereo rear shock absorber (set), rebound and compression damping damping as well as spring preload adjustable, balance tank pivotable (before delivery or before installation of the shock absorber), for Harley Davidson 883 Iron, Type XL 2, model year 2010-, with ABE according to scope of application.

General Description

Adjustline 36 mm radial pistons in precision ground cylinders guarantee optimal function without external diameter space issues.

Adjustline 633
With balance tank on the milled part (Type H40) - the best of the best! The mounting for the pressure reservoir is made of solid aluminium and houses the high- and low-speed compression damping adjustment units. Hydraulic locking and shocks to the chassis are prevented by an overpressure valve. The shock absorber is fully adjustable with 22 clicks each for high-speed, low-speed, and rebound damping. The spring preload can be continuously modified mechanically or even hydraulic. The best materials ensure a long service life and high reliability. Damping and spring are, as always, selected according to rider data!

Features:
- With pivotable balance tank (adjustable at the factory only)
- 22-way adjustable low-speed compression damping damping
- 22-way adjustable high-speed compression damping damping
- 22-way adjustable rebound damping
- Continuous spring preload using the supplied hook wrench

Additional Information and Notes:
- In addition to the basic versions with black (Blackline) and blue (Blueline) spring, for an extra charge, you can have the spring painted by us in all RAL colours. Furthermore, it is possible to order the shock absorber as Wilbers Nightline. The aluminium upper surfaces are matt black anodised in the Nightline, the spring is painted black, and applications serving the setting of the shock absorber are red anodised. For an extra charge, see the form (please specify colour during the ordering process)
- Also available in various lengths for raising or lowering: please inquire about lengths
- Please also specify during the ordering process: rider weight including clothing in kg, pillion weight including clothing in kg, luggage weight in kg, frequency of solo operation without luggage in %, frequency of pillion operation in %, frequency of luggage operation in %, riding style (touring/sporty), intended use (racetrack/street/off-road)
