Wilbers fork Spring Kit, Progressive, for KTM 690 SMC Supermoto, Type KTM LC 4, Model Year 08-11, 90 mm Lowering

Product Details

Wilbers fork spring kit, progressive, for KTM 690 SMC Supermoto, Type KTM LC 4, model year 08-11, 90 mm lowering, including reducing sleeves and reducing sleeves + 20 mm preload spacers, (fork oil please order separately), with ABE according to the application list.

General Description

Depending on the application, Wilbers offers progressive or linear fork springs, made from the best and highest quality chrome-silicon steel. For touring and touring-sport applications, we generally recommend a progressive fork spring to optimise the response and, on the other hand, to increase the bottoming resistance. Crucially, the combination of "Zero Friction" fork springs with the specially developed Wilbers fork oil, as well as observing the correct air chamber for the respective vehicle, is very important. If desired, individual tuning can be achieved in special cases by changing the air chamber. For motorsport applications, we recommend the very lightweight linear chrome-silicon fork springs from Wilbers, which were co-developed with the motorsport team.

"ZERO friction" friction reduction through vibratory finishing:
During vibratory finishing, the workpieces to be processed, such as Wilbers fork springs, are located together with an abrasive media specially adapted for this purpose in a vibrating container, known as a trough vibrator.
The vibrations of the container create a relative movement between the workpiece and the abrasive media, leading to a smoothing of the componentupper surface through constant rubbing against each other. At the end of the process, a fine, shiny surface is achieved.
For Wilbers fork springs, this reduction in surface roughness means a minimisation of friction = ZERO friction.

Each fork spring set includes a recommendation for the viscosity of the fork oil and the air chamber height in the fork. These values have been determined by experienced Wilbers technicians and ensure optimal riding comfort and feedback at the front wheel.

Note: please order the fork oil separately.
