Rubber-damped front sprocket, 15 teeth, 530 pitch
€16.34 gross €18.16 UVP brutto
Product number:
23-155-012-15-G
Product details
Rubber-damped front sprocket, 15 teeth, 530 pitch, for various Yamaha, Suzuki, Kawasaki, Cagiva, and other models.General description
In addition to the original ratios for almost all motorcycle types, we stock a large number of engine sprocket with additional tooth counts, offering many possibilities for individual ratio variants.Rubber-damped front sprockets, which significantly reduce the running noise of the chain, are now standard equipment on many bikes.
To guarantee fast delivery times, we source chain wheels and sprockets from various companies, including JT Sprockets, PBR, AFAM, and Ognibene. The chain wheels and sprockets are made of steel as standard.
| Number of teeth: | 15 |
|---|---|
| Pitch: | 530 |
| Manufacturer | Model | Additional designation | Type | Model year | Note | ccm |
|---|---|---|---|---|---|---|
| Kawasaki | ZZR500 | - | 1990 - 1996 | 500 | ||
| Kawasaki | ZZR600 | ZX600D | 1990 - 1992 | 600 | ||
| Suzuki | GS550 | GS550 | spoked wheels | 550 | ||
| Suzuki | GS550 | GS550D | cast wheel | 550 | ||
| Suzuki | GS550E | GS550E | 1981 - 1981 | cast wheel | 550 | |
| Suzuki | GS550L | GS550E | 1979 - 1979 | cast wheel | 550 | |
| Suzuki | GS550M Katana | GS550M | 550 | |||
| Suzuki | GS550T | GS550E | 1980 - 1980 | cast wheel | 550 | |
| Suzuki | GSF1200 Bandit | GV75A | 1996 - 2000 | without ABS | 1200 | |
| Suzuki | GSF1200 Bandit | GV75A | 1996 - 2000 | without ABS | 1200 | |
| Suzuki | GSF1200 Bandit | GV75A | 1996 - 2000 | with ABS | 1200 | |
| Suzuki | GSF1200 Bandit | WVA9 | 2001 - 2005 | with ABS | 1200 | |
| Suzuki | GSF1200 Bandit | WVA9 | 2006 - | 1200 | ||
| Suzuki | GSF1200 Bandit | WVA9 | 2001 - 2005 | 1200 | ||
| Suzuki | GSF1200 Bandit | WVA9 | 2001 - 2005 | without ABS | 1200 | |
| Suzuki | GSF600 Bandit | GN77B | 1995 - 1999 | 600 | ||
| Suzuki | GSF600 Bandit | WVA8 | 2000 - | 600 | ||
| Suzuki | GSF650 Bandit | WVB5 | 2005 - 2006 | 650 | ||
| Suzuki | GSF650 Bandit | WVB5 | 2005 - 2006 | with ABS | 650 | |
| Suzuki | GSF650 Bandit | WVB5 | 2005 - 2006 | 650 | ||
| Suzuki | GSX1100F | GV72A | 1987 - 1988 | pitch #530 | 1100 | |
| Suzuki | GSX1100F | GV72B | 1987 - 1988 | pitch #530 | 1100 | |
| Suzuki | GSX1100F | GV72C | 1987 - 1988 | pitch #530 | 1100 | |
| Suzuki | GSX1100F | GV72C | 1989 - | pitch #530 | 1100 | |
| Suzuki | GSX1200 | A3 | 1999 - 2000 | 1200 | ||
| Suzuki | GSX400 | GS40X | 1982 - 1982 | 400 | ||
| Suzuki | GSX600F | AJ | 1998 - 1998 | 600 | ||
| Suzuki | GSX750 | AE | 1998 - 2003 | 750 | ||
| Suzuki | GSX750F | AK | 1998 - | 750 | ||
| Suzuki | GSX750F | GR78A | 1989 - 1997 | 750 | ||
| Suzuki | GSX-R1100 | GV73B | 1990 - 1992 | pitch #530 | 1100 | |
| Suzuki | GSX-R1100 | GV73B | 1989 - 1989 | pitch #530 | 1100 | |
| Suzuki | GSX-R1100 | GV73C | 1990 - 1992 | pitch #530 | 1100 | |
| Suzuki | GSX-R1100 | GV73C | 1989 - 1989 | pitch #530 | 1100 | |
| Suzuki | GSX-R1100W | GU75B | 1993 - 1994 | pitch #530 | 1100 | |
| Suzuki | GSX-R1100W | GU75C | 1993 - 1994 | pitch #530 | 1100 | |
| Suzuki | GSX-R750 | GR77B | 1988 - 1989 | 750 | ||
| Suzuki | GSX-R750 | GR79B | 1989 - 1989 | 750 | ||
| Suzuki | GSX-R750 | GR7AB | 1990 - 1991 | 750 | ||
| Suzuki | GSX-R750 | GR7DB | 1998 - 1999 | 750 | ||
| Suzuki | GSX-R750W | GR7BB | 1992 - 1995 | 750 | ||
| Suzuki | RF900R | GT73B | 1994 - | pitch #530 | 900 | |
| Suzuki | VZ800 Marauder | AF | 1997 - 2003 | 800 | ||
| Yamaha | FZR600 | 3HE | 1989 - 1990 | 600 | ||
| Yamaha | FZR600 | 3HE | 1989 - 1990 | 600 | ||
| Yamaha | FZR600 | 3HE | 1991 - 1993 | 600 | ||
| Yamaha | FZR600 | 3HE | 1991 - 1993 | 600 | ||
| Yamaha | FZR600 | 3RG | 1991 - 1993 | 600 | ||
| Yamaha | FZR600 | 3RG | 1989 - 1990 | 600 | ||
| Yamaha | FZR600 | 3RG | 1991 - 1993 | 600 | ||
| Yamaha | FZR600 | 3RG | 1989 - 1990 | 600 | ||
| Yamaha | FZR600 | 3RH | 1991 - 1993 | 600 | ||
| Yamaha | FZR600 | 3RH | 1991 - 1993 | 600 | ||
| Yamaha | FZR600 | 3RH | 1989 - 1990 | 600 | ||
| Yamaha | FZR600 | 3RH | 1989 - 1990 | 600 | ||
| Yamaha | FZR600 | R | 4JH | 1994 - 1995 | 600 | |
| Yamaha | FZR600 | R | 4JH | 1994 - 1995 | 600 | |
| Yamaha | FZS600 Fazer | RJ02 | 1998 - 2001 | 600 | ||
| Yamaha | FZS600 Fazer | RJ02 | 1997 - 2003 | 600 | ||
| Yamaha | YZF600R Thunder Cat | 4TV | 1996 - | 600 |
