EK Chain DEX-chain 520 for On- and Off-Road Motorcycles - 114 Links
€67.72 gross €75.24 UVP brutto
Product number:
23-090-114
Product details
chain EK 520 DEX, extra reinforced, pitch 520, with hollow rivet link, 114 links longGeneral description
Affordable Quadra-X-Ring chain for motorcycles with high tensile strength and smooth running properties:- 520 DEX for on- and off-road motorcycles up to 500 cc
- 525 DEX for on- and off-road motorcycles up to 750/650 cc
- 530 DEX for on- and off-road motorcycles up to 900/750 cc
EK Chain developers have ideally resolved the balancing act between high quality and an affordable price. The extra reinforced DEX chain is equipped with patented Quadra-X-Rings. The QX-Rings optimally retain lubricant between the moving parts of the chain, thus providing excellent protection against wear with very low internal friction.
The high manufacturing quality and the materials used give the DEX a higher breakage load at a low weight than many comparable chains from other manufacturers. Additionally, the chain is manufactured using "Zero Stretch Technology", a controlled stretching process during production. During operation, this results in extremely low elongation, protecting sprockets, chain, and rear sprocket. Furthermore, the DEX also scores with a very good price-power, performance ratio.
Dimensions:
- Inner plate 2.0 mm / Outer plate 2.0 mm
- Pin diameter 5.38 mm
- Overall width 20.1 mm
- Weight per 100 links 1.57 kg
- Tensile strength 3,780 kg
| Pitch: | 520 |
|---|---|
| chain number of links: | 114 |
| Manufacturer | Model | Additional Designation | Type | Model Year | Variant/Version | Note | ccm |
|---|---|---|---|---|---|---|---|
| Aprilia | RX125 | - | 1993 - 2008 | 125 | |||
| Honda | CRF450X | PE06 | 2004 - 2018 | 450 | |||
| Honda | CRF450X | - | 2019 - | 450 | |||
| Honda | CTX700 | RC68 | 2014 - 2016 | 700 | |||
| Honda | NC700S | RC61 | 2012 - 2013 | 700 | |||
| Honda | NC700X | RC63 | 2012 - | 700 | |||
| Honda | NC750S | RC70 | 2014 - 2015 | 750 | |||
| Honda | NC750S | RC88 EURO4 | 2016 - | For SA and SD seat height reduction approx. 35 mm | 750 | ||
| Honda | NC750X | RC72 | 2014 - 2015 | 750 | |||
| Honda | NC750X | RC72 | 2014 - | 750 | |||
| Honda | NC750X | RC90 EURO4 | 2016 - | 750 | |||
| Honda | NC750X | RH09 EURO5 | 2021 - | 750 | |||
| Husqvarna | 701 Svartpilen | HQV701 EURO4 | 2018 - | 701 | |||
| Husqvarna | 701 Svartpilen | HQV701 EURO5 | 2021 - | 701 | |||
| Husqvarna | 701 Vitpilen | HQV701 EURO4 | 2018 - | 701 | |||
| Husqvarna | 701 Vitpilen | HQV701 EURO5 | 2021 - | 701 | |||
| Kawasaki | ER6f | EX650A | 2005 - 2008 | 650 | |||
| Kawasaki | ER6f | EX650C | 2009 - 2011 | 650 | |||
| Kawasaki | ER6f | EX650E | 2012 - | 650 | |||
| Kawasaki | ER6n | ER650A | 2005 - 2008 | 650 | |||
| Kawasaki | ER6n | ER650C | 2009 - 2011 | 650 | |||
| Kawasaki | ER6n | ER650E | 2012 - 2016 | 650 | |||
| Kawasaki | ER6n | ER650E | 2012 - | 650 | |||
| Kawasaki | Ninja 650 | EX650K EURO4 | 2017 - | 650 | |||
| Kawasaki | Ninja 650 | EX650KA2 EURO4 | 2017 - | 35 kW | 650 | ||
| Kawasaki | Ninja 650 | EX650M EURO5 | 2021 - | 650 | |||
| Kawasaki | Ninja 650 | EX650M EURO5 | 2020 - | 650 | |||
| Kawasaki | Ninja 650 | EX650MA2 EURO5 | 2021 - | OEM 35 kW variant | 650 | ||
| Kawasaki | Ninja 650 | EX650MA2 EURO5 | 2021 - | 650 | |||
| Kawasaki | Ninja 650 | EX650S EURO5+ | 2023 - | 650 | |||
| Kawasaki | Ninja 650 | EX650SA2 EURO5+ | 2023 - | A2 | OEM 35 kW variant | 650 | |
| Kawasaki | Versys 650 | LE650A | 2007 - 2010 | 650 | |||
| Kawasaki | Versys 650 | LE650C | 2010 - 2014 | 650 | |||
| Kawasaki | Versys 650 | LE650C | 2011 - 2014 | 650 | |||
| Kawasaki | Versys 650 | LE650E | 2015 - 2016 | also LT | 650 | ||
| Kawasaki | Versys 650 | LE650E | 2015 - 2016 | Euro3 | 650 | ||
| Kawasaki | Versys 650 | LE650E EURO4 | 2017 - | with ABS | 650 | ||
| Kawasaki | Versys 650 | LE650EA2 EURO4 | 2017 - | 650 | |||
| Kawasaki | Vulcan S | EN650A | 2015 - 2016 | 650 | |||
| Kawasaki | Z650 | ER650H EURO4 | 2017 - 2019 | 650 | |||
| Kawasaki | Z650 | ER650HA2 EURO4 | 2017 - 2019 | 650 | |||
| Kawasaki | Z650 | ER650K EURO4 | 2020 - | 650 | |||
| Kawasaki | Z650 | ER650K EURO5 | 2021 - | 650 | |||
| Kawasaki | Z650 | ER650KA2 EURO4 | 2020 - | OEM 35 kW variant | 650 | ||
| Kawasaki | Z650 | ER650S EURO5+ | 2023 - | 650 | |||
| Kawasaki | Z650 | ER650SA2 EURO5+ | 2023 - | A2 | 650 | ||
| Kawasaki | Z650RS | ER650M EURO5 | 2021 - | 650 | |||
| Kawasaki | Z650RS | ER650MA2 EURO5 | 2021 - | 650 | |||
| Kawasaki | Z650RS | ER650R EURO5+ | 2024 - | 650 | |||
| Kawasaki | Z650RS | ER650RA2 EURO5+ | 2024 - | 650 | |||
| Kawasaki | Z800 | ZR800A | 2013 - 2016 | 800 | |||
| Kawasaki | Z800 | e Version | ZR800C | 2013 - | 800 | ||
| Kawasaki | Z800 | ZR800F | 2016 - | 800 | |||
| Kawasaki | ZX-4R Ninja | ZX400P EURO5+ | 2024 - | P1 / E | 400 | ||
| Kawasaki | ZX-4RR Ninja | ZX400P EURO5+ | 2024 - | S1 / E | 400 | ||
| KTM | 390 Duke | KTMISDUKE | 2013 - 2014 | 390 | |||
| MZ | Baghira 660 | MUZ660E | 1998 - 2006 | 17 inch | 660 | ||
| MZ | Baghira 660 | Black Panther | MUZ660E | 1998 - 2006 | 17 inch | 660 | |
| MZ | Baghira 660 | MUZ660E | 1998 - 2006 | 21 inch | 660 | ||
| MZ | Baghira 660 | Street Moto | MUZ660E | 1998 - 2006 | 17 inch | 660 | |
| Suzuki | DR650 | S | SP41B | 644 | |||
| Suzuki | DR650 | RS | SP42B | 1990 - 1991 | 650 | ||
| Suzuki | DR650 | RSE | SP43B | 1991 - 1996 | 650 | ||
| Suzuki | DR650 | R | SP44B | 1991 - 1995 | 650 | ||
| Suzuki | DR650 | SP45B | 1994 - 1995 | RE/REU | 650 | ||
| Suzuki | RGV250 | VJ22B | 1991 - 1996 | 250 | |||
| Suzuki | RV200 Van Van | WVBT | 2016 - 2019 | 200 | |||
| Yamaha | WR400F | CH | 1999 - 2002 | 5GS | 400 | ||
| Yamaha | WR426F | CJ | 2001 - 2002 | 5NG | 426 | ||
| Yamaha | WR450F | CJ | 2003 - 2009 | 5TJ | 450 | ||
| Yamaha | XV125 Virago | 5AJ | 1997 - | 125 | |||
| Yamaha | XV250 Virago | 3LS | 1989 - 1993 | 250 | |||
| Yamaha | XV250 Virago | S | 3LW | 1989 - 1998 | 250 | ||
| Yamaha | YZ250 | CG | 2005 - 2006 | 1P8 | 250 |
