BITUBO Cartridge for Honda CBR1000RR 2008-11
€1,257.69 gross €1,323.88 UVP brutto
Product number:
BI-H0133-EBH00WO
Product Details
BITUBO Cartridge without springs, spring preload 15mm (15 turns) adjustable, one leg with rebound damping adjustable in 24 clicks, one leg with compression damping damping adjustable in 24 clicks; for Honda CBR1000RR, Type SC59, from model year 2008 - 2011General Description
The EBH gas-pressurised cartridge features a range of innovative components.Lightweight Components:
This product is manufactured with a large proportion of special light alloys, significantly reducing its weight.
The adjusters for the various setting options are located on the upper end caps:
The spring preload can be adjusted over 15 turns, while the rebound and compression damping damping are split between the two cartridges, making adjustment simpler and easier.
The Goal:
To offer the rider the greatest stability on the front wheel, achieved through perfect feedback from the front wheel, even under the heaviest strain on the brakes and in extreme lean angles. Due to direct hydraulic control, grip is increased when entering and exiting a corner, and more even tire wear is achieved.
Features:
- Hydraulic piston with FPS® System - made of aluminium
- with anti-friction coating
- Polyurethane end stop
- co-axial compensation chamber
- Hydraulic oil & sliding grease separated
- compression damping 24 clicks
- Rebound 24 clicks
- spring preload 15 mm - 15 turns
| fork filter: | Cartridge |
|---|
| Manufacturer | Model | Type | Model Year | Note | Homologation | Position | ccm |
|---|---|---|---|---|---|---|---|
| Honda | CBR1000RR Fireblade | SC59 | 2008 - 2011 | without ABS | ABE pending | Front | 1000 |
