Cordona 428SPEC GP ASG Superbike for Yamaha YZF-R6 WSS Mectronik from model year 2019-

€462.99 gross €389.07 net

Product number: COR-428SPEC

ask for delivery time

Product details

Cordona 428SPEC GP ASG Superbike Quickshifter with blipper function; ready-to-install delivery consisting of module, sensor, and shift rod (160 mm), for Yamaha YZF-R6, WSS Mectronik, from model year 2019-

General description

The CORDONA GP ASG Quickshifter with blipper function significantly improves shifting performance and reliability compared to OEM and other competition. It offers superior clear and smooth shifting performance, similar to top GP and WSBK systems. It features an analogue strain gauge for ECUs with upshift function and auto blipper for downshift function. Used by advanced ECUs such as Magneti-Marelli, Motec, Mectronik, MotoGP ECUs, as well as many OEM and flashed ECUs for street motorcycles with an analogue 0-5V input.

Compared to OEM and other quickshift systems, the Cordona ASG Superbike is faster, more precise, and smoother. The motorcycle requires less traction control and doesn't upset the chassis as much during shifting, especially when leaned over.

Specification:
- 0-5v analogue, high-sensitivity strain gauge GP ASG Superbike sensor
- Load cell technology and no moving parts in the sensor
- 5-15v DC power supply
- Analogue output to motorcycle ECU, 2.5 V (at idle), range 0.5 to 4.5 V
- 20MHz processor with adaptive calibration for temperature and vibration
- Configurable push or pull direction
- Can be used for ECUs equipped only with upshift functionality
- Fully sealed and weather-protected sensor and module
- High-precision CNC-machined housing from stainless steel
- Dimensions: 45 mm long, 14 mm diameter
- M6 "magic thread", left-hand and RH thread in both sensor ends
